Adventure Works brand package now available!


Super short post today.

With the release of an updated test/demo Azure VM for Power BI Report Server on Monday, we thought it made sense to provide a new Adventure Works brand package for everyone to use in their demos/presentations to go along with it.  Feel free to download and use with Reporting Services 2016/2017 or Power BI Report Server – https://1drv.ms/u/s!Au6-0xX27UdgnOIapntXPaoPcqqOWQ

Thanks!

Tiggee, Batman and Power BI Premium

WP_20130922_114

On the eve of the Microsoft Data Insights Summit, I thought I’d finally write the story behind the picture I’ve included with this post.  How does this story relate to the recent announcement around Power BI Premium?  Well, I’ll leave that up to you to decide if it does, or if it’s simply a cute little story that involves my son Matthew (who has been bugging me to write about him on here).

A couple years ago, my son asked his sister Caitlin and I to play Monopoly with him.   We happily agreed, and went downstairs to the family room.  But we didn’t see the usual setup.  Instead, we were greeted with what you see in the picture.

“What the heck is this?” his sister asked.  “This isn’t Monopoly!”

“I know – now it’s AWESOME Monopoly!” he replied.

“Awesome Monopoly?  That sounds stupid.  I don’t want to play that.”

“C’mon, please – it’ll be fun.”

“No it won’t – it looks dumb.  I’m going back upstairs.”  With that, she turned and stomped out of the room, taking Happy Bear with her.

I winced.  This had played out many times before, and the ending had always been the same.  I glanced towards the kitchen, seeing if the tissue box was still sitting on the counter from an earlier incident.  But it wasn’t needed – he just smiled, sat down and started re-arranging Batman to make room for me.

“She’ll be back,” he said.  “You’ll still play with me, won’t you dad?”

“Um, sure.  Awesome Monopoly sounds, um, awesome,” I said, not quite sure what I was in for.

He tried to explain the rules , and I’ll admit, they seemed pretty confusing the first time he explained them to me.  I don’t remember everything he laid out, but one rule he mentioned during this initial explanation was if you rolled a 12 and landed on “Chance”, Batman got put in jail for a turn OR you had to draw a playing card.

“Buddy, I gotta be honest – I don’t fully understand some of these rules you’ve added.” I told him.  “Do you think we could make it a little less confusing?”

“What do you mean?  We haven’t even started yet.”

“Yeah, I know, but some of these rules . . .”

I didn’t want to push too hard, but at the same time, I couldn’t imagine the game going well if the Elf on the Shelf remained the banker for the entire game.

“Okay, new rule!  We can always change the rules if we decide they’re dumb.”

“Really?” I asked.

“Yep – that’s why it’s Awesome Monopoly.  We can keep making it more and more awesome together!”

I shook my head and laughed.  “Sure, pal, that sounds fair.  I’ll let you go first.”

We went a few rounds, me laughing and him asking me each time someone went how he could make it even more “awesome”.

“I’ll admit, pal, this is a lot of fun.”

“Yay – I knew you’d like it!  Can you go tell Caitlin how much fun it is?”

“Sure.”

I nodded, left the room, and came back with her having agreed to play after hearing how it great it was (and Happy Bear even came back too).

“Caitlin’s back – woohoo!”  He proceeded to run around the room and make sounds like a choo-choo train.  “Yayyyy!”

The game played out, and any time someone thought of a way to make the game even more awesome, we talked about it, tweaked the rules and kept making the game more and more awesome!  (My kids used to like to say awesome A LOT).

So what’s the moral of the story?  It’s either –

1. Batman cheats

or

2. Power BI Premium = Awesome Monopoly.

or

3. Chris needs better blog topics

If you’re coming to Seattle for the conference, I’ll see you next week!

Using URL parameters with Mobile Reports in Reporting Services


One area I’ve found folks looking for additional information recently has been how to use URL parameters with Mobile Reports in SQL Server 2016 Reporting Services.  This was a fairly popular feature in Datazen, so naturally people want to use it in SQL Server 2016 as well.

Quick background for folks who don’t know what URL parameters are in the context of mobile reports.  You can create a mobile report with parameters in SSRS 2016 so you and your report readers can filter your reports.  This is helpful when you have a large dataset, for example, so not all the records are loaded at once (If you aren’t familiar with how to write a shared dataset query with parameters in Reporting Services, you can learn more about that at this link – https://msdn.microsoft.com/en-us/library/dd239345.aspx).  Sometimes, you’ll want to provide those parameters as part of the URL for the report.  This can be useful if the report is a drill-through target from another report you’re viewing, for example.

First off, there is support for this feature.  You can find documentation on MSDN for it here – https://msdn.microsoft.com/en-us/library/mt772301.aspx

The article, however, only covers the basic scenario around using a dataset parameter.  Dataset parameters are passed on to the shared dataset that they were specified for when you created the mobile report. The parameter name must be specified as:

<Dataset Name>.<Parameter Name>

Below is a sample URL for supplying a value for the @Reqtype parameter of for an ExecutionLogs dataset:

http://rsserver/Reports/mobilereport/ExecutionLogs%20with%20Filter?ExecutionLogs.@Reqtype=Subscription

There are also parameters that are tied to the selection state of the control in the mobile report it was specified for.  These can be thought of as selection control parameters.  An easy way to find the name of the selection control to use in your URL is on the “Set drillthrough URL” screen in Mobile Report Publisher.


Like dataset parameters, the parameter name must specified in the following manner:

<Control Name>.SelectedItem
<Control Name>.SelectedItems

Below are sample URLs for specifying these:

http://rserver/Reports/mobilereport/ExecutionLogs%20with%20Filter?SelectionList.SelectedItem=Subscription

http://rsserver/Reports/mobilereport/ExecutionLogs%20Multi?SelectionList.SelectedItems=Subscription,Interactive

A special type of selection control in Mobile Reports is the Time Navigator control.  The time navigator control supports the following properties you can set in your URL –

– SelectedStartTime
– SelectedEndTime
– ViewportStartTime
– ViewportEndTime

The values for these properties are date time values formatted like this – “2017-02-15T00:00:00”.

Please Note: the “:” character needs to be URL encoded as “%3A” (browsers will usually do this automatically for you).

Now please read carefully the following item, because here’s where folks often run into trouble – if a user specifies a dataset parameter value via the URL and there is also a selection control wired up to supply values for the very same dataset parameter, a conflict occurs. The mobile report resolves this conflict by applying the dataset parameter value supplied via the URL (and discarding the initial selection control value). Note that this is true even as the user starts interacting with the report and chooses other selection values!

You can easily avoid this by supplying a selection control parameter via the URL instead of a dataset parameter.  The MSDN article is being updated to reflect this information as well, but keep this in mind when you are designing your mobile reports.

Finally, there is an item you can apply to your entire report via URL, and that’s to enable/disable showing the report title.

To disable the title, simply add “?title=false” to your URL, so it looks like the following –

http://rserver/reports/mobilereport/Claims%20Trends?title=false

If you want to show the title, just don’t add this to your URL.  Simple enough, right?

Hope this has been helpful for you and helped clear up a few things on this topic.  I want to give a special thanks to Andre M. from the engineering team for helping me with this blogpost.

How to insert a live Power BI report from SQL Server Reporting Services into a PowerPoint slide


Yay – the long awaited installable version of the Technical Preview of SQL Server Reporting Services is finally here.

Though very similar in functionality to what was first released on an Azure VM back in October, one item now officially supported that wasn’t previously is using https on your report server.  With this change, you can now use the Web Viewer add-in for PowerPoint 2013/2016 to surface live Power BI Reports from your server.  This is the same functionality already available for both paginated and mobile reports that I’ve walked through previously.  Here’s how you can try this functionality out as well with the Technical Preview –

1.  Go to the Insert Tab in PowerPoint.  You should see the Store Add-In in the ribbon.  Click it to open the App Store –
OfficeSnip
2.  A pop-up will open with the apps available in the store.  You can now run a search for the app you wish to use

Type Web Viewer into the search bar and hit Enter.  You see the Web Viewer app created by Microsoft, which is what we’ll use.


From here, you’ll need to enter the address for your Power BI report (and make sure you have https configured for your server!)  You need to use the “rs:embed=true” url pattern in the address, which we first introduced in SQL Server 2016.  Otherwise, you will see the following error –

When I use that address, it works just as one would expect in the preview –


You can also take advantage of row-level security in your report, which will flow through to the PowerPoint slide, by either using Kerberos or EffectiveUserName for your Analysis Services data source.


One suggestion is that you don’t use self-signed certificates with this feature – I have found the web viewer control doesn’t always work well with these (as anyone who saw my attempt to demo this at PASS can attest to.)

Thanks for reading and give this a try – it’s something we’ve heard from a lot of people wanting to take advantage of!

Why Mobile Reports and Power BI Reports aren’t a zero sum decision in SQL Server Reporting Services

There are two questions I’ve gotten for months.  And with the first public preview of Power BI reports in SQL Server Reporting Services, they’ve grown louder in the past week or so.

“Will we be able to view Power BI reports hosted in SSRS in the Power BI mobile app?” (Yes, we’re planning to support that scenario)

“If so, why should I still use mobile reports?” (Sigh)

I’ll admit, I understand one of the biggest driving factors around this question is not wanting to “bet on the wrong horse”.  And yes, a major reason people are concerned about doing that is because of, well, Microsoft and some decisions made at various points in the company’s history around certain products.  But I can only offer my opinion on this particular question and what I’d tell a customer if they asked me question two today.

Recently, Power BI added the ability to create mobile optimized layouts for reports.  But no one has been asking if they should still create mobile optimized dashboards now that they have this new functionality.  Why not?  Because they aren’t really an either/or proposition.  You have a dashboard to give you an overview of your business metrics, and then can dig into more detail by clicking a tile and jumping into a report.  In the context of SQL Server Reporting Services, it’s probably better to compare the mobile report use case to Power BI dashboards rather than Power BI Reports.

By doing so, it helps customers avoid the single biggest issue people run into today with mobile reports (and previously Datazen).  What’s the issue exactly?  Well, they’re trying to use it to build reports the same way they do with Power BI Desktop.  They want interactive reports that allow drag and drop, ad-hoc analysis and can handle hundreds of thousands of records in a data model they build on the fly.  They did this previously because they didn’t have an option to run Power BI reports on-prem.  Now that they will, that shouldn’t be an issue any longer and they can use the best tool for that purpose, which is Power BI Desktop.

Similarly, there are certain use cases today where it may be advantageous to build a mobile report as my “dashboard”, instead of just building it in Power BI Desktop directly.  Today, a few of these include –

– I need my mobile report to be available for my users offline and still be fully interactive.  Power BI reports are viewable offline, but have certain limitations.

– I like having the thumbnail view of my mobile reports on devices for my users to see a quick preview of what the report looks like, especially in combination with KPI’s I’ve created.

– I can add URL’s that link to other content from items on my mobile report, or add url parameters to pass with that as well.

– Some users have specifically told me they like the fact they can add content from different data sources to a mobile report without building another data model.  Why?  They can then filter across all of those data sources in a mobile report, which I know some folks have wanted to see in the dashboards in Power BI.

– I need to view the reports in a mobile phone browser vs. the app.  For on-prem customers, there are often additional challenges having users leverage native apps to view the content vs. a web browser on the device.  The Mobile Reports will look the same in a phone browser as they will in the mobile app, and for some customers, that’s pretty important.

Sure, there are other benefits I get from mobile reports as well, including the whole “design first” option.  But doing a “feature shootout” as of today misses the point – I see mobile reports as a complimentary item to Power BI Reports, just as they are a complimentary item to paginated reports.  They give users an additional way to meet their customer’s needs, and could play a huge part in a customer’s solution, or no role at all.  And since we’ve already stated that adding Power BI dashboards is not on the short term roadmap, I feel very comfortable telling users there is a lot of business value you can derive out of using both options with SQL Server Reporting Services for the foreseeable future.

Now, could that change down the road?  Could Power BI Desktop becomes the single tool used to create mobile and paginated reports in addition to what it does today?  After all, we stated in our blogpost last year that “We intend to standardize reporting content types across Microsoft on-premises, cloud and hybrid systems.”  Does that mean we could consolidate everything into one tool as well?  I guess, but there’s a pretty healthy debate you can have on whether its better to have one tool to do everything, or specialized tools for each report type.  Trust me, I’ve been in this debate many times already.  And it’ll really depend on what it always does – what do our customers think is the best option moving forward?

There you have it – one man’s opinion on the subject.  And I’m sure there are people who will read this and disagree completely.  Great – I wouldn’t have it any other way.  🙂

Feel free to let me know what you think in the blog comments, and have a great week!

Ten things you might have missed in the Technical Preview of Power BI Reports in SQL Server Reporting Services


Whew – this is my fourth (and final!) blogpost in four days around the Technical Preview for SQL Server Reporting Services.  It’s been a lot of work, but also a lot of fun putting these together.  For my final post, I wanted to touch on ten items you’ll see (and can try) in the preview to ensure you don’t miss them.

Before I do that, however, I wanted to take a moment to say “Thank you”.  This past week at PASS Summit 2016, and the reaction from the community to this entire preview, has been one of the highlights of my entire career.  I got to meet several of you for the first time at PASS, and as you learned very quickly, I’m not someone to sugarcoat things.  You all embraced this very unique preview and made the engineers who were on-site at PASS from the Reporting Services team feel like the rock stars they are.  That type of passion and energy is so infectious, again, I can’t thank you enough for letting the team know how excited you were with what we’ve delivered to date.  Our customers are the reason we fought so hard to bring this to you, and I promise, this is the just the first step.  We’re already back at it, working hard to bring you the first installable preview of this functionality as quickly as possible.

1. You can access your VM in Azure through a web browser

If you’d like other users to view and interact with the technical preview without remoting into the VM.  This is helpful if you’d like to show it to additional people in your organization, give users read-only access, etc.  Keep in mind, you’ll still need to do all creating/editing of Power BI Desktop reports on the VM directly using Remote Desktop.

To try this out, find the public IP address of the VM in Azure listed in the essentials section


Open a web browser on your local machine and type in the address/reports in the following format – http://8.8.8.8/reports (enabling https for the VM is something that is a little tricky to do, so I’ll have to decide whether that’s worth doing a future post around or not).  Enter your username and password for the VM, and you’ll be granted access to the report portal.

2. You can use embed the Power BI Reports just like mobile and paginated reports.

If you’d like to see your Power BI Report in an iFrame, you can add ?rs:Embed=true at the end of the report url.  For example, here is the embed url for the Sample Sales Report when connected directly to the VM via remote desktop – http://localhost/reports/powerbi/Sample%20Sales%20Report?rs:embed=true


3.  Mobile Reports and Power BI Reports both are available in the execution logs.

This is a common request for those folks interested in seeing when people ran certain reports and how often they did so.  If you go into the ReportServer database catalog via SQL Server Management Studio and run a query using the ExecutionLog3 SQL view, you’ll see log entries for both of these report types now show up –


4.  Direct url navigation is now available for KPI’s.


Users have so liked the new reporting services interface, they’d asked for an easy way to link to other content directly from the portal homepage so everyone can use the new portal as a starting point in their organization.  With this in mind, we added an additional option to KPI’s called “Direct Navigation”.  This allows you add a custom url as related content, just like you can in the portal currently, and simply bypass the current KPI pop-up action you get when you click on the KPI and go directly to the linked content.

For any KPI’s that you use this feature with, you’ll a little “link” in the upper right-hand corner of it so you can tell that it is enabled.  This will give the ability to create “dummy” KPI’s that you use just to link to outside content.


5.  You can turn report comments off for certain users by creating a custom role in SQL Server Management Studio and assigning it to them for folders/reports.


One piece of customer feedback we got when considering the comment feature was the need to give report owners the ability to restrict certain users from adding or viewing comments.  To accomplish that, we added new tasks for comments in Reporting Services that are assigned to security roles.  Security Roles in Reporting Services are managed through SQL Server Management Studio.  You can create a new role without these permissions and assign them to users accordingly by following the steps in this article.  (We’d recommend you hold off on changing the security roles for the Power BI reports in the Technical Preview, since we’re aware of an issue that was reported on another blog.)

6. You can favorite Power BI Reports just like any other report type


7. You can install another instance of Analysis Services on the same machine to have both Multidimensional and Tabular running simultaneously.


During setup, you get the option to run the VM with either Tabular or Multidimensional mode already running (along with demo Power BI content tailored for it).  However, if you really want to have both modes available on your machine, the developer edition installation files used for both the database engine and Analysis Services are located here on the VM – C:\SQLServer_13.0_Full

Simply add a new stand-alone instance of Analysis Services on the same machine and you’ll have both options available to build reports against.

8. You now have the option for a “List” view of your items in the portal


Simply toggle the layout option in the View menu in the portal to switch view types.

9.  A new, expanded context menu is available when you click the ‘…’ option for that item.


You’ll hear much more about items 8&9 in a future blog post on the Reporting Services team blog.

10. The Technical Preview VM will expire in six months.

Also note, the expiration date is six months from the date it was first made available in the portal.  Just be aware of this, and keep in mind you’ll probably want to migrate any content you put on there prior to this date.

And we’re done – finally, I can take a few hours to relax and watch the big Eagles/Cowboys game this evening.  I’m in such a good mood, I might not even care if the Eagles lose to Dallas.

Yeah, no, I’ll care – Go Birds!

Embed from Getty Images

How to run the Technical Preview of Power BI Reports in SQL Server Reporting Services on-prem using Hyper-V

hypervfinished

What a week!  With the announcement and release this week of the Technical Preview of SQL Server Reporting Services in Microsoft Azure, it’s been a whirlwind of activity and excitement.  And while people have generally been excited to go ahead and spin it up in Azure, there are still some folks who’d like to try out the preview on their local PC using Hyper-V.  Here’s how you can do just that.  I’ll also point out one big “gotcha” that I ran into doing it this way –

1.  Go through all the initial steps outlined in this blog post to get the machine up and running in your Microsoft Azure account.

2.  In Azure, find the Virtual Machine you just created and stop it by clicking the stop button.

stopvm

3.  Now, navigate to the resource group you created that contains the virtual machine.  You’ll see it setup several items, including two storage accounts.  Select the storage account that has “vhd” in the lengthy name, as this is where the virtual hard drives are stored.


4.  As you click into the storage account details, you’ll see two disk drives – one is labelled “dataDisk.vhd”, and the other is labelled “osdiskforwindowssimple.vhd”.  “osdiskforwindowssimple.vhd” is the one you need to download.

vhdinfo

5.  You now have a couple options – you can simply click the download button that appears when you select the vhd, or you can use a separate program that may help accelerate the download process (remember, the file is quite large).  These (free!) options include –

Microsoft Azure Storage Explorer
Azure Explorer from RedGate
AzCopy (advanced users only)

No matter which way you download it, the file will take awhile depending on your internet connection since it is 127 GB.  You might consider letting it run overnight like I did.

6.  Once your download is finished, you’ll need to setup a new virtual machine in Hyper-V to mount the virtual hard drive on.  This also means you need to have Hyper-V turned on in Windows.  With Windows 10, just follow the instructions in this walkthrough to do so.  If you have Windows 7, you can follow these instructions instead.

7.  Launch Hyper-V Manager on your PC to get started.  Select New Virtual Machine

newvirtualmachine

I’d recommend you name this new machine the same name you gave it in Azure, just for consistencies sake.  It isn’t required, but you might find it less confusing.  Hit Next

Choose “Generation 1” for this virtual machine.  Hit Next

You need to assign the amount of memory you’d like to make available to this virtual machine.  I’d strongly recommend assigning a minimum of 4 GB of memory to the virtual machine (remember, the machine we recommend in Azure has 28GB of memory), and really 8 GB (or more) is preferred.


For the purposes of this blog post, I am not going to assign a virtual network option for the machine.  This means I can’t access the internet from the VM (so Bing Maps won’t work if I choose a map visual), but I’m doing that to show you that yes, it can run entirely on-premises with no cloud dependencies.


Finally, I’ll select the virtual hard disk I downloaded from Azure to attach to the machine.


I’ll hit finish, and my new VM will show up in my list of virtual machines in Hyper-V manager.


8.  Here’s where the big “gotcha” is/was – if you right-click on the VM and hit “Start”, it will attempt to start and then fail with an error message saying “The Version Does Not Support This Version of the File Format” or something to that effect.  The issue is related to the fact we didn’t dismount the hard drive from the Azure VM (which I didn’t want to do, because I wanted to spin it back up again in the future in Azure).  To workaround this, you need to have Windows unmark the .vhd as a sparse file.  There are several ways you could accomplish this, but the easiest I found was with a program called Far Manager, which is free to download and use.

Once you’ve installed it, open the program and click on the “n” in the upper left-hand corner (don’t be scared of the GUI, it’s easy, trust me).


A window will pop-up showing all of your local hard drives – browse to the drive you vhd is on.


Select the vhd from the file list and hit ctrl-A.  A new menu will pop-up and you’ll see a box marked “Sparse”.  Uncheck that box and the click { Set }


It’ll take awhile to finish doing that (10-15 minutes in my case), but once it’s done, go ahead and try starting your virtual machine again.  You won’t get that nasty error any longer.

9.  It’ll take a few minutes to boot up and finish prepping.  When it’s finished, you can login with the administrator username and password you used when first creating the VM.  You’ll now be using Power BI Reports in Reporting Services entirely on-prem.


I’ll be back tomorrow with some tips and tricks you might not be aware to help you get the most out of this technical preview.  Until then, have a great Saturday!
